| Rated voltage of battery |
25.6V |
51.2V |
| Rated energy of battery |
2.56kWh |
5.12kWh |
5.12kWh |
7.68kWh |
10.24kWh |
14.336kWh |
16kWh |
| Rated capacity of battery |
100Ah |
200Ah |
100Ah |
150Ah |
200Ah |
280Ah |
314Ah |
| Configuration of cells |
8S1P |
8S2P |
16S1P |
| Working voltage range |
22.4V~28.4V |
44.8V~56.8V |
| Charging cut-OFF voltage |
22.4V |
56.8V |
| Discharge cut-OFF voltage |
28.4V |
44.8V |
| Maximum charging current |
100A |
100A |
100A |
150A |
150A |
200A |
200A |
| Maximum discharge current |
100A |
100A |
100A |
150A |
150A |
200A |
200A |
| Charging temperature range |
0℃~60℃ |
| Discharge temperature range |
-20℃~60℃ |
| Suggested discharge depth |
80% |
| Max. number of parallel batteries |
16 |
| Supporting communication methods |
RS232/MODBUS/CANBUS |
